TODCOLD
Insulated Roll-Up Doors
Introducing the coolest new member of the roll-up door family. TODCOLD insulated doors are independently tested and proven to be among the lightest weight and most thermally efficient roll-up doors on the market. Designed to lower fuel costs, reduce environmental impact, and minimise equipment wear, TODCOLD doors deliver reliable performance for temperature-controlled transport applications. All doors are backed by a 12-month limited warranty.
Standard Features
- Insulated fibreglass slat construction
- Panel thickness options:
- 28mm (1 1/8″)
- 65mm (2 1/2″)
- 1″ Track system
- Improved veil material for smoother curtain finish
- Polyaspartic painted top coat
- Aluminium bottom angle
- E-coated counterbalance (C/B) assembly
Available Options
- EZ Seals™ Dual Durometer side seals
- Long Life SuperRollers™
- Everware™ hardware (inside & out)
- Hold-open door keeper
- Removable end hinges
TODCOLD – Chiller Door
Temperature Rating: Down to -10°C
The TODCOLD Chiller door is specifically designed for chilled transport applications. The 28mm (1 1/8″) panel consists of a pultruded fibreglass shell with 2.0mm walls, filled with high-performance polyurethane foam. Polypropylene end caps enhance thermal efficiency, while an integrated vinyl joint seal prevents moisture and dust ingress.
The rigid, polyurethane-filled fibreglass construction provides excellent resistance to punctures and dents while maintaining superior insulation properties. The smooth panel surface allows for easy application of paint or decals, with no through-fastenings in the centre of the wide slat door.
Panel Construction
- Fibreglass shell with polyurethane foam core
- Thickness: 28mm (1 1/8″)
- Suitable for temperatures down to -10°C
TODCOLD – Freezer Door
Temperature Rating: Down to -20°C
Designed for deep-freeze environments, the TODCOLD Freezer door features a 65mm (2 1/2″) insulated panel constructed from a pultruded fibreglass shell with 2.0mm walls, filled with polyurethane foam. Polypropylene end caps and an integrated vinyl joint seal ensure excellent thermal performance while preventing moisture and dust penetration.
The strong, rigid construction delivers high impact resistance and long-term durability. A smooth exterior surface allows for branding or decals, with no central through-fastenings across the wide slat curtain.
Panel Construction
- Fibreglass shell with polyurethane foam core
- Thickness: 65mm (2 1/2″)
- Suitable for temperatures down to -20°C
Applications
- Refrigerated trucks
- Chiller and freezer bodies
- Temperature-controlled transport
- Food, pharmaceutical, and cold-chain logistics
